Studio System™ 2

AISI 4140 is versatile and is mainly used in the automotive sector.

AISI 4140 is characterized by its toughness, high fatigue strength, and abrasion and impact resistance, and is an excellent general-purpose steel for industrial applications.

Yield strength 1060 MPa

Tensile strength 1450 MPa

Elongation at break 5,5%

Hardness 40 HRB

Density (relative) 95%

Chromium-molybdenum alloyed quenched and tempered steel, versatile with high strength and toughness for highly stressed components, such as pinions, connecting rods and transmission shafts.

Area of application in automotive and mechanical engineering.

H13 is characterized by its hardness and abrasion resistance.

The material also has exceptional heat resistance, resistance to thermal fatigue and stability during heat treatment. This makes H13 tool steel an ideal material for hot and cold work applications such as molds.

Yield strength 650 MPa
Tensile strength 1325 MPa
Hardness 35 HRC
Density (relative) ≥ 93.5

Hot work tool steel with very good hot strength properties, high hot wear resistance, and good toughness and thermal conductivity.

The material is water-coolable and insensitive to fire cracking.

Applications are die casting tools, press dies, press mandrels, ejectors and plastic molds.

17-4 PH is a precipitation hardening steel used in a wide range of industrial applications. The material is ideal for mildly corrosive environments and applications with high strength requirements.

Yield strength 660 MPa
Tensile strength 1042 MPa
Elongation at fracture 8.5%
Young's modulus 195
GPaHardness 37 HRC
Density (relative) 98

Combines very good corrosion resistance, with high strength and good toughness.

Fully age-hardenable, with excellent notched impact strength even at sub-zero temperatures.

Applications Plant, machinery and shipbuilding, petroleum industry and the wood and paper industry, as well as medical technology.

Assembly jigs and tools.

316L is a stainless steel characterized by its corrosion resistance and reliability, both at high and low temperatures, ideal for extreme environments.

D2 is a high chromium tool steel specially developed to provide high abrasive wear resistance and high hardenability.

Yield strength 420 MPa
Tensile strength 860 MPa
Hardness 255 HB
Density 7.7 g/cm³

Low distortion cold work tool steel with good dimensional stability, high wear resistance and toughness combined with high compressive strength.

Applications Dies, punches, measuring tools, pressing tools and high performance cutting tools.

Copper, with its excellent thermal and electrical conductivity, is the ideal material for heat exchangers and similar applications. For this reason, it is used in virtually every electronic device, as well as in the oil and gas, automotive and consumer industries. Desktop Metal enables the processing of copper in office environment!

Composition 99,9% Cu + 0,01% O
Tensile strength 195 MPa
Elongation at break 37%
Electrical conductivity 85.2%
IACS Density 8.75 g/cc

Applications Conductors, heat exchangers, inductors, erosion nozzles.

An alloy of titanium, aluminum and vanadium.

Among the material properties of Ti64, the high strength-to-weight ratios and corrosion resistance are particularly impressive. These make it an ideal material for a wide range of high-performance applications.

Yield strength 730 MPa
Tensile strength 845 MPa
Elongation at break 17
Density (relative) 97.5%

High strength titanium alloy, with excellent corrosion resistance, with good hot workability and weldability.

Excellent fatigue strength, with high resistance to crack formation and crack propagation.

Applications:

Compressor blades, housings and bolts for engines in the aerospace industry, valves and connecting rods in the automotive industry, medical devices, power engineering (wind, water and nuclear energy).
